This section presents two VPN designs:

 The first connects a client from two remote locations to two corporate sites. This redundancy solution is enhanced by the use of load balancers (not shown in the diagram, as they would be located within the NAT blocks) at the corporate sites. These load balancers distribute traffic between the two data centers while simultaneously monitoring all destinations to dynamically disconnect unresponsive services from the service pools.
